Dali Thermal Imaging FPA Detector 160*120 25um Core sensor

FOB Reference Price:Get Latest Price
$2.00 - $10.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
Dali
Model Number:
DLC160(25μm)
Usage:
Household
Theory:
Infrared Thermometer
Accuracy:
0.1℃
Temperature range:
2000℃
Material:
amorphous silicon
Spectral range:
8-14μm
Packaging & Delivery
Port
Hangzhou



FPA Detector

Description



The Uncooled Microbolometer infrared FPA detector researched and developed by Dali has already been applied in industrial production. It has the advantages of high resolution, high sensitivity, low thermal noise and fast response. The detector are much suitable for thermography,security surveillance, vehicle night vision and various other applications.



Features



 160×120 resolution (25um)

 Frame rate 30~100Hz

 High uniformity, low thermal noise

 Short integral time, high sensitive

 xtended operating temperature range -40℃ to +60℃

 Military standard qualification

 Fully self-intellectual property

ItemDLC160 (25μm)
Materialamorphous silicon
Array size160×120
Pixel pitch25μm
Fill factor≥60%
Spectral range8-14μm
Temperature controlTEC
Frame rate30-100Hz
NETD≤60mK(f/1,300K,30-100Hz)
Thermal time constant≤5ms
Responsively≥8mV/K
Operability≥99%
Power supply5V
Power consumption≤100mW(excluding TEC)
Outputsingle analog output
Dimension20.8mm×14.6mm×6.5mm(pin is not included)
Weight≤6g
Operating temperature-40°C - +60°C
Storage temperature-40°C - +85°C
StandardsMIL-STD-810 and -883
