DALI S230 hunting type thermal monocular

FOB Reference Price:Get Latest Price
$3,000.00 - $5,000.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
DALI
Model Number:
S230
Features:
Un-cooled FPA micro-bolometer
Array size:
384x288
IFOV:
1.36mrad
Frame frequency:
50/60Hz
Focus:
manual
Zoom:
2X
Spectral range:
8-14um
Display:
800x600 HD OLED monocular screen
Image Polarity:
White/Black hot
Supply Ability
Supply Ability:
200 Unit/Units per Week
Packaging & Delivery
Packaging Details
basis on incasement request
Port
shanghai
Lead Time :
2-4 WEEK



S230





 384×288 uncooled FPA detector
 1.8-meter drop resistance
 One-hand operation, carrying light
 Monocular OLED display
 Good performance

S230  infrared monocularsItemsTechnical Specification
Detector characteristicsDetector typeUn-cooled FPA micro-bolometer
Array size/format384x288
Image characteristicsField of view/min focus distance29.9°×22.6°/0.1m
Spatial resolution(IFOV)1.36mrad
Thermal sensitivity≤0.06°C@30°C
Frame frequency50/60Hz
Focusmanual
Zoom2X
Spectral range8-14um
Image displayDisplay800x600 HD OLED monocular screen
Image PolarityWhite/Black hot
Image storageStorage card2G Micro SD card
Storage modeManual
File formatJPEG/MPEG4
Thermal image operationPower keyOn/Off switch
Brightness key5 optional cycle levels
Zero keyManual calibration
Function keyShort press for E-zoon,long press for polarity shift
Storage/Record keyCapture/record
Power sourceBattery typeLi-Ion, rechargeable
Battery operating time3 hours continuous operation
Battery charging modeSpecial designed,random charge
Power saving10-15 V DC
External power<3.5W
EnvironmentOperating temperature-20°C-- +50°C
Storage temperature-40°C-- +60°C
Humidity≤90% non-condensing
EncapsulationIP67
Drop test1.8M,IEC68-2-32
Shock-resistant25G,IEC68-2-29
Anti-vibrated2G,IEC68-2-6
Physical characteristicsWeight<900g
Dimension139x64x163mm
InterfacePower interfaceYES
Video outputYES
USBImage, measurement data transfer
